Presonus Audiobox USB96

Presonus Audiobox USB96

$99.95

Categories ,

Description

Presonus Audiobox USB96



The blue PreSonus AudioBox USB 96 is a 2×2 USB audio interface offering Class-A mic preamps with 48V phantom power, MIDI I/O, and simple operability in a portable and sturdy steel chassis that is conveniently bus powered, making it a great solution for singers, musicians, podcasters, and producers recording at home or on the go.

The AudioBox USB 96 utilizes 24-bit converters at sampling rates up to 96 kHz to ensure the integrity of your signals. The two XLR-1/4″ combo inputs let you record microphones (dynamic or condenser) or instruments such as electric guitar while monitoring with zero latency. Stereo 1/4″ monitor and headphone outputs are provided with independent volume controls for optimal hookup of speakers and headphones.

The interface is bundled with the Studio One Artist DAW software for Mac and Windows, and includes the Studio Magic plug-in suite, delivering effects, virtual instruments, and third-party loops, software, and instrument sounds.

AudioBox USB 96

  • Bus-powered USB audio and MIDI interface
  • Perfect match with Studio One Artist software for Mac and Windows
  • 24-bit resolution
  • 44.1, 48, 88.2, and 96 kHz sampling rates
  • Two XLR-1/4″ combo mic/instrument inputs with Class-A mic preamplifiers
  • 48V phantom power
  • Zero-latency monitoring via internal analog mixer
  • Two 1/4″ balanced monitor outputs
  • 1/4″ headphone jack with level control
  • MIDI 5-pin input and output ports
  • Sturdy steel chassis
  • 1/3 RU rackmountable
  • USB computer-to-interface connection cable included

PreSonus AudioBox 96 Specs

Interface
Channels of I/O Analog:
2 Inputs / 2 Outputs at 96 kHz
Max Sample Rate/Resolution 96 kHz / 24-Bit
Number of Mic Preamps 2
Input Level Adjustment 2 x Knob
Pad None
High-Pass Filter None
Display and Indicators 1 x LED (Power)
1 x LED (+48 V)
2 x LED (Clip)
Expansion Slots None
Connectivity
Host Connection 1 x USB Type-B (USB 2.0)
Analog I/O 2 x Combo XLR-1/4″ TS Balanced/Unbalanced Mic/Hi-Z Input (Pin 2 Hot)
2 x 1/4″ TRS Balanced Monitor Output
1 x 1/4″ TRS Unbalanced Headphone Output
Phantom Power +48 V, Selectable On/Off (Applied to All Inputs)
Digital I/O None
MIDI I/O 1 x MIDI 5-Pin In
1 x MIDI 5-Pin Out
Memory Card Slot None
Performance
Frequency Response Mic Inputs:
20 Hz to 20 kHz ±3 dB
Headphone Outputs:
20 Hz to 30 kHz ±1 dB
Gain/Trim Range Mic Inputs:
0 dB to +60 dB
Hi-Z Inputs:
-10 dB to +30 dB
Monitor Outputs:
-80 dB to +10 dB
Max Input Level Mic Inputs:
-3 dBu (1 kHz, Unity Gain)
Headphone Output Power 60 mW per Channel into 60 Ohms (Max)
Dynamic Range AD/DA Converters:
105 dBA (48 kHz Sample Rate)
Impedance Mic Inputs:
1.2 Kilohms (Balanced)
Hi-Z Inputs:
0.5 Megohms (Unbalanced)
Outputs:
51 Ohms (Balanced)
THD+N Mic Inputs:
<0.008% (1 kHz, Unity Gain)
SNR 95 dB (Unity Gain)
CMRR >45 dB (1 kHz, 55 dB Gain)
Digital Audio
dBFS Reference Level +4 dBu = 0 dBFS
Sample Rates 44.1, 48, 88.2, 96 kHz
Bit Depth 24-Bit
Sync Sources Internal
Compatibility
OS Compatibility macOS 10.11 or Later (64-Bit Only)
Windows 7 or Later (32-Bit, 64-Bit)
Compatible Software (Not Included) Any Core Audio Compliant Software
Included Software Studio One Artist
Processor Requirement Mac:
Intel Core Duo
PC:
Intel Core 2
RAM Requirements Mac:
2 GB, 4 GB Recommended
PC:
4 GB, 8 GB Recommended
Storage Requirements 20 GB
Minimum Display Resolution 1024 x 768
Required Hardware Available USB 2.0 Port
USB Cable (Included)
Internet Connection Required for Registration, Software/Driver Download
Power
Power Requirements USB Bus Power
Physical
Anti-Theft Features Kensington Security Slot
Dimensions 5.5 x 5.5 x 1.75″ / 13.97 x 13.97 x 4.45 cm
Weight 5.0 lb / 2.7 kg
Packaging Info
Package Weight 2.33 lb
Box Dimensions (LxWxH) 10.05 x 6.75 x 3.7″

Additional information

Weight 1 lbs
Dimensions 5 × 5 × 5 in
