Tascam DA-6400 DP Series 64-Channel Digital Multitrack Recorder


Compare

$3,999.99

The DA-6400 DP from Tascam is a 64-channel digital multitrack recorder/player that records to an internal SSD caddy for live and event recording. With I/O options like MADI and DANTE, it is ideal for live recordings, event capture, or to a backup for critical DAW sessions. In addition, the DA-6400 is a suitable option for professional remote recording.

Furthermore, the recorder/player features an AK-CC25 hot-swappable caddy containing a 240GB Tascam solid-state drive, and the caddy includes a USB-3 jack for stand-alone use. This allows you to hand the drive to the client to offload the BWAV-files into their DAW session. The DA-6400 records 64 tracks at 48 kHz/24-bit or 32 tracks at 96 kHz/24-bit. Also, included on the rear panel are SMPTE timecode, word clock, RS-422, parallel, Ethernet connections and two power supply inlets.

The I/O options for the DA-6400 include the IF-MA64/EX interface card (sold separately), with both coaxial and optical MADI connections. This card contains a redundant coaxial connection so that MADI is passed through even if power is lost, making it an ideal backup recorder for DAW sessions. Additional cards (sold separately) include the IF-MA64/BN coaxial MADI card, IF-DA64 Dante card, and IF-AE16 AES/EBU card, with more to come.

In conclusion, the Tascam DA-6400 combines high performance, flexibility, and complete reliability in a solid-state 64-track recorder.



Item# TEADA6400DP

UPC: 043774031610
SKU: TEADA6400DP Category: Tags: ,

Tascam DA-6400DP Specs

Recording Media SSD
Note: HDD support also planned in addition to the SSD.
File System FAT32
File Formats BWF (.wav)
Number of Channels 64 (1xFs), 32 (2xFs)
Sampling Frequencies 44.1, 48, 88.2 & 96 kHz
Bit Rate 16-bit, 24-bit
Clock Reference Input Internal, Word In, Video In
Timecode Frame: 24/25/29.97DF/29.97NDF/30DF/30NDF
Time Code Input
Connector BNC
Signal Voltage Amplitude: 0.5 V to 5 Vp-p
Input Impedance 10 KOhms
Format SMPTE 12M-1999 compliant
Time Code Output
Connector BNC
Signal Voltage Amplitude: 2 Vp-p
Output Impedance 600 Ohms
Format SMPTE 12M-1999 compliant
Word/Video In
Connector BNC
Input Voltage (WORD) 0.5 V to 5 Vp-p TTL equivalent
Signal Voltage Amplitude (Video): 1 Vp-p
Input Impedance 75 ohms +/-10%
Input Frequency Word: 48 kHz
Input Signal Word: 24/25/29.97/30 Frame (NTSC/PAL black burst, HDTV tri-level)
Word/Video Thru/Out
Connector BNC
Output Voltage Amplitude: 5 V TTL equivalent
Output Frequency Word: 48 kHz
Ethernet
Connector RJ-45
Protocol 100Base-TX, 1000Base-T
Connectors
RS-422 D-sub 9 pin (female, inch-standard)
Parallel Port D-sub 15 pin (female, inch-standard)
USB Connector: USB 2.0 A-type
Protocol: USB 2.0 high speed (480 Mbps)
Phones Connector: 1/4″ (6.3 mm) standard stereo jack
Maximum Output Level: 45 mW+45 mW or higher
Power & Other Parameters
Power 2x AC 100 V-240 V, 50/60 Hz
Power Consumption 21 W (at the time of IF-MA64/EX use)
Operating Temperature 32 to 104°F (0 to 40°C)
Dimensions (W x H x D) 18.2 x 1.7 x 12.0 (462.6 x 44.7 x 304.8 mm)
Weight 7.5 lb (3.4 kg)
Packaging Info
Package Weight 14.05 lb
Box Dimensions (LxWxH) 21.3 x 16.3 x 5.4″
