Tascam CD-RW901MKII Professional CD Recorder


The Tascam CD-RW901MKII is a professional-quality CD recorder that can be mounted in a standard audio rack.  High-quality 24-bit A/D and D/A converters provide terrific audio quality.  The unit can record and play CD-R/RW discs as well as play discs that are written with MP3 files.

Standard features of the player include front-panel playback controls, a large information display, a wired remote control, and stereo RCA I/O connectors.  More advanced features include automatic sample rate conversion, selectable disc reading speed, auto cue and auto ready, pitch control of 0.1 to 1.0%, and more.  Optical and coaxial digital I/O connectors are also provided for maintaining a digital signal from start to finish, and analog and digital XLR connectors let you connect to most professional audio gear.  Additional connectors include parallel and RS-232C ports for wired control.

Rack mountable slot-loading CD recorder
Reads and records CD-R/RW and can play back MP3 CDs
24-bit A/D and D/A converters for high-quality audio
Front-panel playback and adjustment controls
Front-panel headphone jack with independent volume control
Stereo analog RCA and XLR I/Os
Digital I/O includes TOSLink optical, S/PDIF coaxial, and AES/EBU XLR connectors
Parallel and RS-232C control ports
Large information display
Selectable disc reading speed
Sample rate conversion between 32kHz to 48kHz so you can work with virtually any audio source
Timed track feature lets you add a track ID to a CD every 1-10 minutes while recording
Skip mode offers index searching and a time skip function
Auto cue and auto ready features
Wired remote control included
Two units may be connected for continuous recording
Pitch adjustments on playback from 0.1 to 1.0%
Auto or manual track dividing
Sync record start
Repeat all, single track, or A-B repeat
CD-RW discs can be erased or unfinalized
Dedicated input level controls for left and right channels
CD-TEXT and MP3 ID3 tag display
PS/2 keyboard input for CD-TEXT input and control
Digital fade in/out while recording
Dimensions: 19″W x 3.875″H x 12″D.
Be Sure to Checkout Our Selection CD’s


UPC 043774030637



Tascam CD-RW901MKII specs

Supported Disc Types CD-R, CD-R-DA, CD-RW, CD-RW-DA (High Speed CD-RW is supported)
Playback Capability CD-DA, CD-ROM ISO9660 LEVEL 1/2 Joilet format, multisession discs and CD-text
Playback Formats CD-DA: 44.1 kHz, 16-bit, stereo
MP3: 44.1 kHz, 64 to 320 kbps, VBR
Recording Formats CD-DA: 44.1 kHz, 16-bit, stereo
Analog Inputs RCA pin jack, unbalanced
XLR-3-31 (1: GND, 2: HOT, 3: COLD), balanced
Analog Input Impedance 22 kΩ /-10%, unbalanced
Reference Input Level -10 dBV (Full scale -16 dB), unbalanced
-4dBu (Full scale -16dB), balanced
Minimum Input Level -19 dBV (adjustable level at full scale -16 dB), unbalanced
-5dBu (adjustable level at full scale -16dB), balanced
Input Impedance 14 kΩ /-5%, balanced
22 kΩ /-10%, unbalanced
Analog Outputs RCA pin jack, unbalanced
XLR-3-32 (1: GND, 2: HOT, 3: COLD), balanced
Output Impedance 200 Ω, unbalanced
75 Ω /-5%, balanced)
Reference Output -10 dBV /-2 dB (full scale -16 dB), unbalanced
4 dBu (full scale -16 dB), balanced
Maximum Output Level 6 dBV /-2 dB, unbalanced
20 dBu, balanced
Digital Input RCA pin jack, coaxial, IEC60958-3 (S/PDIF) format
TOS LINK, optical, IEC60958-3 (S/PDIF) format
XLR-3-31, AES/EBU, IEC60958-4 (AES/EBU) format
Digital Output RCA pin jack, coaxial, IEC60958-3 (S/PDIF) format
TOS LINK, optical, IEC60958-3 (S/PDIF) format
XLR-3-32, AES/EBU, IEC60958-4 (AES/EBU) format
Headphones Connector: 1/4″ (6.3 mm) stereo phone jackOutput Power:  20 mW 20 mW or more (32 Ω loaded)


Keyboard Connectors Mini DIN 6-pin
Control I/O D-sub 9-pin, RS-232C
D-sub 15-pin, parallel
Remote RC-RW901 connector
Frequency Response Playback: 20 Hz to 20 kHz, /-0.8 dB
Recording: 20 Hz to 20 kHz, /-1.0dB
S/N Ratio Playback: 95 dB
Recording: 90 dB
Dynamic Range Playback: 95 dB
Recording: 90 dB
Distortion Playback: 0.006%
Recording: 0.008%
Channel Separation Playback: 90 dB (1 kHz)
Recording: 80 dB (1 kHz)
Wow and Flutter Unmeasurable (0.001% or less)
Power North America: 120 VAC, 60 Hz
Power Consumption North America: 17 W
Dimensions 19.0 x 3.7 x 12.2″ (482.6 x 94.0 x 309.0 mm)
Weight 9.9 lb (4.5 kg)
Packaging Info
Package Weight 13.35 lb
Box Dimensions (LxWxH) 21.5 x 15.0 x 7.2″
