Samson SERVO 300 - Power Amplifier

Samson SERVO 300 – Power Amplifier

$299.99

Categories ,

Description

Samson SERVO 300 – Power Amplifier



The Samson SERVO 300 is a 2-channel, 300-watt 2RU rackmount power amplifier, suitable for powering small to medium sized P.A. systems or integrated conference room audio systems.

The SERVO 300 features large, 10-segment, 3-color level LED meters and independent channel volume controls. The rear panel includes 1/4-inch balanced and RCA input connectors, as well as 5-way binding post and 1/4-inch speaker outputs.

The SERVO 300 also features 4-stage power protection circuitry that ensures optimal performance, overload protection of connected components, and cooler more efficient operation. This is a durable, versatile power amplifier that inexpensively serves the musical, corporate and educational communities.

2-channel rackmount power amplifier with 150 Watts per channel at 4 Ohms, 300 Watts Bridged Mono at 8 Ohms
4-stage protection circuitry includes Short Circuit, Thermal, Current Limit, DC Offset, Current Inrush, RF Protection, Power On/Off Muting
Accurate 10-segment, 3-color Level LED meters, Peak and Signal LED indicators for each channel
1/4″ Phone balanced, RCA Phono unbalanced input connectors, 5-way binding post and 1/4″ outputs
Versatile and durable for smaller school or club P.A. systems and conference room installation audio applications
UPC: 809164005476

Samson Servo 300 Specs

Power Amplifier
Number of Channels 2
Power Rating 8 Ohms:
100 W per Channel
300 W Bridged
4 Ohms:
150 W per Channel
Performance
Protections On/Off Muting
Frequency Response 20 Hz to 20 kHz +0/-0.5 dB
5 Hz to 60 kHz +0/-3 dB
Damping Factor 280
Input Sensitivity 1.24 V / 4 dBu
Input Impedance 15 Kilohms (Unbalanced)
30 Kilohms (Balanced)
Max Gain 33 dB
SNR 102 dB
THD 0.01% (Full Range, at Rated Power -10 dB)
0.1% (1 kHz, at Rated Power)
Connectivity
I/O 2 x 1/4″ TRS Balanced Input
2 x RCA Input
2 x 5-Way Binding Post Pair Output
2 x 1/4″ TS Output
Power
Current Consumption 4 Ohms:
0.7 A (1/8 Power)
1.7 A (1/3 Power)
5 A (Full Power)
Physical
Display & Indicators 2 x Multi-Segment LED Meter
1 x Blue LED (Power)
1 x Amber LED (Protect)
1 x Green LED (Signal, per Channel)
1 x Red LED (Peak, per Channel)
Cooling Fan (Variable Speed)
Dimensions 19.0 x 3.5 x 11.7″ / 483.0 x 89.0 x 297.0 mm
Weight 20 lb / 9.1 kg
Packaging Info
Package Weight 23 lb
Box Dimensions (LxWxH) 21.4 x 14.9 x 6.6″
