Specifications
Brightness (Typical) 6000 ANSI Lumens
Native Resolution WXGA (1280 x 800)
Max. Resolution WUXGA (1920 x 1200) @60Hz
Contrast Ratio 10,000:1 (Full On/Off)
Lamp Life and Type 1,500/3,500 Hours (Normal/Eco), 370W/280W
Lamp Part # 5811119760-SVV
Display Type Single 0.65” DLP® Technology by Texas Instruments
Throw Ratio (±3%) 1.32 to 2.24:1 (Distance/Width)
Image Size (Diagonal) 21″ to 360″ (0.0.53 to 8.93m)
Projection Distance 3.28’ to 32.8’ (1.0 to 10 m)
Projection Lens F=2.45 – 3.22, f=18.8 – 32mm
Zoom Ratio 1.7:1 Manual Zoom/Focus
Aspect Ratio 16:10 Native, 4:3, and 16:9 Compatible
Offset 134.3% / 117.1%
Keystone Correction ± 30° Vertical, Horizontal ± 25°
Color Spectrum 1.07 Billion
Horizontal Scan Rate 15, 31 ~ 91.4KHz
Vertical Scan Rate 24 ~ 30Hz, 47 ~ 120Hz
3D Functionality Full 3D (Via DLP® Link™, Blu-ray and Broadcast 3D)
Speaker 3D Audio Surround Sound (7Wx2)
Lens Shift Range Vertical: +24%, -13%
Horizontal: +/-11%
Remote Control Fully Featured IR Remote
Projection Method Table Top or Ceiling Mount (Front or Rear)
Uniformity 85%
Computer Compatibility WUXGA, UXGA,WXGA, SXGA+, SXGA, XGA, SVGA, VGA Resized;
VESA Standards; PC and Macintosh Compatible
Video Compatibility HDTV (1080i/p, 720p), SDTV(480i, 576i), EDTV (480p, 576p),
SDTV(480i, 576i), NTSC 4.43, PAL B/G/H/I/M/N 60, SECAM
I/O Connection Ports HDMI v1.4, MHL/HDMI v1.4, VGA-In (x2), DVI-D, Component
(5 BNC) (RGBHV), S-Video, Composite Video, Audio-In RCA
(L/R), Audio-In (Mini-Jack)(x3), Microphone-In (Mini-Jack),
Wired Remote-In (Mini-Jack), VGA-Out, Audio-Out (MiniJack), Audio-Out RCA (L/R), 12v Screen Trigger (Mini-Jack), 3D
Sync-Out, RS-232, USB Type A (File Reader/USB Host), USB
Type B (Service), USB Display (MINI B), USB Type A (Wireless
Dongle), , Wired Remote-Out (Mini-Jack), RJ45, HDBaseT
Security Kensington® Lock Port, Security Bar
Weight 15lbs (6.8kg)
Dimensions (W x D x H) 17.5″ x 12.9″ x 6.3″ (445 x 330.2 x 160.2mm)
Noise Level 33dB/39dB (Eco/Normal)
Power Supply: AC 100-240V, 50/60Hz
Consumption: 430W/530W (Eco/Normal)
<0.5W (Standby Mode)
Operating Temperature 41 to 104°F (5 to 40°C)
Warranty 3-Year Limited Parts/Labor, 1-Year Lamp
Standard Accessories AC Power Cord, VGA Cable, Remote Control, Batteries for
Remote, Lens Cap, User Manual (CD), Warranty Card
Optional Accessories Wireless Collaboration System NovoConnect B360
UPC 813097020321
