Galaxy Audio Traveler 10″ 150W Peak PA System with Dual-Wireless Receiver, Bodypack, Headset Mic & Handheld Microphone


Compare

$1,109.98

Galaxy Audio Traveler 10″ 150W Peak PA System with Dual-Wireless Receiver, Bodypack, Headset Mic & Handheld Microphone



Intended for people looking for relatively portable, lightweight, and uncomplicated PA systems, this Galaxy Audio Traveler TV10 comes with a bodypack transmitter, a dual-wireless receiver, a wireless handheld microphone, and a headset microphone to get you up and running right away. The PA itself provides 150W peak / 100W RMS power through its 10” woofer and 1” tweeter. It provides four inputs, accommodating XLR, 1/4”, RCA, and 3.5mm connections. Each input provides its own channel control, and you’ll also be able to tweak the sound with a two-band EQ. A master volume is on hand for global level adjustments.

At 44 lb—and measuring 12.2 x 14.2 x 22.8”—the PA itself would be relatively easy to carry about town. However, a retractable handle and wheels have been built into the Traveler TV10, making transportation even more of a cinch. A modular design allows you to plug-in what Galaxy Audio calls “Function Modules” as needed. So, if you need a Bluetooth receiver, a CD/MP3 player, or a single-wireless mic receiver, you can easily insert one into the back.

This particular Traveler TV10 ambles your way with a dual-wireless receiver primed to handle both microphones, giving you a range of 160 to 230’ in an open field. This will come in handy, as the supplied transmitter meets those specifications. The headset mic is looped around both ears and provides a unidirectional capsule to ensure legibility. The wireless handheld microphone provides a dynamic capsule and a cardioid polar pattern.

PA at a Glance
  • 100W RMS/150W peak
  • 10″ woofer / 1″ horn
  • Built-in battery and charger
  • Includes TVHH Wireless Dynamic Handheld microphone and TVMBP Bodypack Transmitter
  • 2 x microphone inputs
  • RCA & 3.5mm outputs
  • Master volume control
  • Built-in Bluetooth
  • Optional media player
  • 4-bar battery indicator
  • Voice priority
  • Built-in wheels and handle
  • Battery operation: 7.5 to 16 hours
  • Speaker-stand mount
Handheld Mic at a Glance
  • 96 selectable channels
  • Channel selector
  • LCD display
  • Dynamic capsule
  • Built-in antenna
  • 3-bar battery condition indicator
  • High/low volume and mute switch
  • Accepts 2 x AA Batteries for 14-hour lifespan (batteries available separately)
  • DC charging input
Bodypack at a Glance
  • 96 selectable channels
  • Channel selector
  • LCD display
  • Built-in antenna
  • 3-bar battery condition indicator
  • High/mid/low sensitivity control and mute switch
  • Accepts 2 x AA Batteries for 14-hour lifespan (batteries available separately)
  • DC charging input



Headset Mic at a Glance
  • Unidirectional headset microphone
  • Hooks over both ears
UPC 646685032983



Category:
Power Output 100 W RMS, 150 W peak
Impedance 4 Ohms
Max SPL 112 dB
Frequency Response 20 Hz to 20 kHz (audio)
Speaker 10″ LF woofer, 1″ HF tweeter
S/N Ratio 70 dB
Sensitivity 92 dB at 1 W / 1 m
Audio Inputs 1 x XLR Microphone input
1 x 1/4″ Microphone input
1 x 3.5 mm Auxiliary input
2 x RCA Line inputs
Audio Outputs 2 x RCA Line outputs
1 x 3.5 mm Auxiliary output
Controls Wireless, MIC, Bass, Treble, Master, AUX & LINE
Power Requirements 100 to 240 VAC, 50 / 60 Hz
Operating Distance Up to 200′ / 61.0 m
Mount Size 1.4 / 35 mm
Dimensions 12.2 x 14.2 x 22.8″ / 310.0 x 360.0 x 580.0 mm
Weight 44.1 lb / 20.0 kg (batteries included)
Battery 2 x 12 V, 4.5 Ah 2 (Lead-Acid) rechargeable batteries
Battery Life (approx.) 4 to 6 hours (tested at over ten hours)
Battery Charging Time 5 Hours
Receiver
Oscillation Type PLL synthesized control OSC
No. of Channels 96, pre-programmed
Switching Bandwidth 12 kHz, maximum
Ambient Temperature 14 to 122°F / -10 to 50°C
Maximum Deviation 50 kHz, with level limiting
Dynamic Range 110 dB
THD Less than 0.5%
Pre-Emphasis 50 μs
Squelch Tone key and noise lock dual-squelch
Frequency Range 70 Hz to 16 kHz, wireless
Operating Range 160 to 230′ / 50 to 70 m, open field
Antenna Single
Sensitivity 4 μv at 30 dB SINAD
Double Intermediate 110.6 MHz / 10.7 MHz
Display Status LCD indicator displays channel or frequency
Controls Channel Select Keys: Sync, up, and down
Spurious Rejection RF: 70 dB
Adjacent Channel Crosstalk 68 dB at 250 kHz
IMD 58 dB IMD rejection
Carrier Frequency Range 520 to 544 MHz
Dimensions 5.3 x 3.4 x 1.5″ / 133 x 88 x 37 mm
Weight 3.9 oz / 110 g
Transmitter
Type Bodypack
RF Output 10 mW
Spurious Emission Less than 250 nW
Indicators LCD indicator displays channel or frequency, also battery life
Controls Channel Select Keys: Set, up, down
AF Controls: Mute switch, Hi/Mid/Low switch
Audio Input Mic in, auxiliary in
Power Supply 2 x AA batteries
Battery Life Approximately 11 to 14 hours
Dimensions 3.5 x 2.5 x 1.0″ / 88 x 64 x 27 mm
Weight 4.5 oz / 127 g
Microphone
Model HS-U3BK Uni Headset
Type Unidirectional headset microphone
Design Hooks over both ears
Sensitivity -65 ±4 dB (0 dB = 1 V / UBR 1 kHz)
Frequency Response 50 Hz to 18 kHz
Output Impedance 2 kOhms max
Working Voltage 1 to approximately 10 V (3 V standard working voltage)
Current Consumption 250 uA (max)
Max SPL 110 dB
S/N Ratio > 38 dB
Microphone
Model TVHH Dynamic Handheld
Type Dynamic, handheld
Pattern Cardioid
RF Output 10 mW
Spurious Emission Less than 250 nW
Channels 96, selectable
Antenna Built-in
Indicators LCD display, 3-bar condition indicator
Controls Channel select keys, High/low volume and mute switch
Power Supply 2 x AA batteries
Battery Life Approximately 14 hours
Charging Input DC
Dimensions 1.8 x 10.4″ / 46 x 264 mm
Weight 9.9 oz / 280.0 g
