Description

CROWN XLS 2002 POWER AMPLIFIER

The next generation of XLS got a makeover with a sleek new look, a LCD display that is three times larger, and more DSP with higher capabilities. Like its predecessor, the new XLS is ultra-efficient with Crown’s patented DriveCore technology and can drive 2400W at 4Ω bridged with tons of headroom guaranteeing a clean, undistorted signal straight to your speakers. The XLS DriveCore 2 assures that you will be heard as you deliver a powerful, pure sound experience for any venue.

Item# CRNXLS2002

UPC: 691991001086

Crown Audio XLS2002 specs

Connectors	Input: 2x XLR 2x RCA 2x 1/4″ / 6.35 mm (can be used as a loop-thru to other amplifiers)Output: Binding Post (Channel 1 & 2): 2 pair 4-Pole speakON: 2 (Channel 1 offers Channel 1 & 2 wiring or Bridge Mode wiring)
Sensitivity	1.4 Vrms
Amplifier Power	1050 W at 2 ohm per channel 650 W at 4 ohm per channel 375 W at 8 ohm per channel 2100 W at 4 ohm bridged 1300 W at 8 ohm bridged
Frequency Response	At 1 W, 20 to 20,000 Hz: +0 dB, -1 dB
Signal to Noise Ratio	>103 dB (at 0.775 Vrms sensitivity, Signal to Noise is 6 dB lower)
THD	<0.5%
Intermodulation Distortion	<0.3%
Damping Factor	>200
Crosstalk	At 1000 Hz: >85 dB At 20,000 Hz: >55 dB
Dimensions (W x H x D)	19 x 3.5 x 10.7″ (48.3 x 8.9 x 27.2 cm)
Weight	10.8 lb (4.9 kg)
