Sennheiser TeamConnect SL Ceiling 2 Microphone Array

Sennheiser TeamConnect SL Ceiling 2 Microphone Array

$4,889.00

Categories ,

Description

Sennheiser TeamConnect SL Ceiling 2 Microphone Array

The TeamConnect SL Ceiling 2 Microphone Array from Sennheiser is designed to provide better audio quality for voice and video conferences. It features adaptive beamforming technology that automatically follows the active speaker’s voice, letting people speak naturally whether they are sitting, standing, or walking around the room.

TeamConnect Ceiling 2 offers great versatility and interoperability with support for Dante networks and POE (Power over Ethernet). It is compatible with Sennheiser’s Control Cockpit software for efficient remote management and offers remote configuration and monitoring via an open media control protocol (API), allowing for easy integration into media systems. A 3-pin Phoenix connector and eight self-adhesive rubber feet are also included.

Ceiling microphone array with patented automatic speaker position detection and dynamic beamforming for best speech intelligibility
Analog and digital (Dante) audio outputs for easy connectivity to video and audio conference systems
Configuration and monitoring via Sennheiser´s Control Cockpit software
Open API for media and camera control applications
Several installation options via suspension kit, flush mount or surface bracket (sold separately)
Key Features
  • For Fixed Conference Installations
  • 28 Sennheiser KE 10-237 Mic Capsules
  • Automatic Beamforming Technology
  • Focuses on Whoever Is Speaking in Room
  • 2 x Dante Interface with RJ 45 Outputs
  • 3-Pin Terminal for Analog Audio Output
  • RJ 45 Ethernet for Network Control
  • Sennheiser Control Cockpit Software
  • Includes a 3-Pin Phoenix Connector
  • 8 x Self-Adhesive Rubber Feet

UPC: 615104311893

Sennheiser Teamconnect SL Specs

Audio Output
1 x 3-Pin Terminal (Fits Phoenix Contact MCVW 1.5-3-ST-3.81)
2 x Digital Dante Network Audio
(RJ-45 Primary and Secondary)
Ethernet Control
1 x RJ-45 Ethernet Port for PoE Power Supply and Data/Control Communication
Supply Voltage
44 to 57 VDC
PoE IEEE 802.3af Class 3
Power Consumption
Maximum 8.8 W
Plenum Rating
Tested According to UL 2043
Transducer Principle
Pre-Polarized Condenser Microphone
AF Frequency Response
160 Hz to 18 kHz
Sensitivity
0 dBV/Pa (988 mV/Pa)
Signal to Noise Ratio
83 dB (A)
Latency
4 ms
Equivalent Noise Level
11 dB (A)
Polar Pattern (Microphone)
28 Capsules
Pick Up Pattern
Beam Pattern
Max Sound Pressure
104 dB SPL
Dynamic Range
93 dB (A)
Temperature
Operation: 32 to 104°F / 0 to 40°C
Storage: 14 to 140°F / -10 to 60°C
Humidity (Relative)
20 to 95% Non-Condensing
Dimensions
23.2 x 23.2 x 1.7″ / 59 x 59 x 4.3 cm
Weight
12.5 lb / 5.7 kg
Packaging Info
Package Weight
18.73 lb
Box Dimensions (LxWxH)
27.4 x 27.4 x 5.3″

Additional information

Weight 1 lbs
Dimensions 24 × 24 × 2 in
