Furman P-1800 PF R Power Conditioner/Surge Suppressor

Furman P-1800 PF R Power Conditioner/Surge Suppressor



Furman P-1800 PF R Overview


Engineered specifically for use with instrument amplifiers and other high-current equipment, the Furman P-1800 PF R offers a stable, protected and filtered low impedance power supply for maximum performance of connected electronics. Furman’s exclusive Power Factor provides a 45A peak current reservoir to minimize the detrimental effects of line impedance on high-current gear such as amplifiers and powered monitors. Clear Tone Technology provides additional line noise filtration tuned for instrument amplifiers for clean and consistent tone. Plus, equipment benefits from professional-level protection thanks to Furman’s exclusive SMP and EVS technologies.

Power Factor Technology

Power Factor Technology supplies 45+ amps of instantaneous reserve current, on demand, for power starved amplifiers

Clear Tone Technology

Clear Tone Technology provides tuned filtering circuits engineered for instrument amplifiers to provide a clean and consistent tone

Surge Protection

Furman’s exclusive SMP technology provides the highest level of surge & spike protection available

Noise Filtration

LiFT offers AC power filtering to ensure clean power for unequaled audio & video clarity

Voltage Protection

Advanced EVS circuitry detects dangerous voltage irregularities and safely powers down itself and connected equipment in unsafe conditions

Diagnostic Lights

LED status indicators warn you when voltage is outside of nominal range or when protection has been compromised

Isolated Banks

Isolated outlet banks minimize inter-component interference and noise contamination


Large digital voltmeter with discrete dimmer button displays incoming line voltage

Wall Wart Spacing

Three widely spaced outlets accommodate bulky AC power transformers

15A Rating

15 amp rating featuring a high inrush magnetic circuit breaker for added protection

Nine Total Outlets

Nine total outlets (8 rear panel outlets and one front panel convenience outlet)

BNC Lamp Connector

Rear panel BNC connector powers any standard gooseneck lamp for rear rack illumination

USB Charger

Front panel USB convenience outlets allows you to charge most media devices or power a USB lamp
UPC: 654061028123
Maximum Current 15A@124V
Output 90 to 139VAC
Surge Energy Rating 188VAC peak @ 3,000A
Dimensions 19 x 12 x 1.75″ (482.6 x 304.8 x 44.45mm)
Weight 13 lbs (5.9kg)
Equipment Protection Line to neutral, zero ground leakage
