Description

Tascam VSR-264 Live Streaming (HDMI)

The Tascam VSR-264 Stand-Alone Full HD Video Encoder/Decoder for Live Streaming streams and records up to 1920 x 1080 over IP. It simultaneously records video, encodes, streams, and decodes multiple streams using the H.264 codec. It supports encoding at up to 30 Mb/s using H.264 and can record to either SD cards, or attached USB drives.

The TASCAM DISCOVERY app allows you to remotely manage multiple units via an easy-to-use web GUI. After setup, all settings are saved locally to the individual VS-R units, so they can operate without being controlled by a computer. The unit powers by PoE+, allowing you to place it anywhere you can run an appropriate Ethernet cable connected to a router that supports PoE+. If that is not possible, an AC power adapter is available. Mounting brackets are included, and an optional AK-RS1 shelf allows you rackmount two units side-by-side.

Encoding for Streaming Services

The VSR-264 live stream encoder is an external stand-alone YouTube encoder that also provides Full HD streaming to popular Content Delivery Networks (CDNs) including Wowza, Ustream, AWS Elemental MediaLive, and CloudFront among others.

The balanced analog Euroblock/Phoenix low-voltage wire connectors and unbalanced analog 3.5mm mini-stereo jacks provide audio I/O connections for a variety of commercial AV over IP environments, including corporate, education, house of worship, government, industrial, and security.

Audio can be embedded from analog sources and de-embedded to drive networked audio playback, likewise digital audio within the HDMI I/O can be used. An integrated output level configuration function and reference level switching function (up to +20 dBu) allows reliable and flexible system structuring when streaming video.

The VSR-264 live streaming encoder is compatible with popular standard streaming protocols, including HLS, RTMP, RTP/RTSP. Additionally it allows both Multicast and Unicast. The RESTful API is supported for integration into control systems in commercial AV installations.

The VSR-264 can record directly to USB connected media or SD cards via a front-panel loading slot.

Recorded files can be automatically uploaded to an FTP server for creating back-up copies, editing, or re-purposing to the web.

The Mac/Windows compatible “TASCAM DISCOVERY” app allows multiple VS-R units connected to the network to be managed from a simple Web-browser based GUI. All configuration settings are saved within the VS-R devices, so that in normal operation no computer is needed for streaming or recording.

PoE+ functionality eliminates the need for AC adapters in AV installations. An optional TASCAM AC power supply (sold separately) is available where external AC power is required.

UPC: 043774034185

Tascam VSR-264 Specs

IP Encoding/Decoding

IP Video	H.264: 720 x 480 to 1920 x 1080 at 23.98p, 24p, 25p, 29.97p, 50i, 59.94p, 60p Encoding
Transport Protocols	RTMP, RTSP
Simultaneous Streams	2 Streams

Interfaces

Video Connectors	1 x HDMI (HDMI 1.4a) Input 1 x HDMI (HDMI 2.0) Output
Audio Connectors	1 x 1/8″ / 3.5 mm TRS Stereo Analog Input 1 x 6-Pin Euroblock Stereo Analog Input 1 x 1/8″ / 3.5 mm TRS Stereo Analog Output 1 x 6-Pin Euroblock Stereo Analog Output
Other I/O	1 x RJ45 10/100/1000 Ethernet Input/Output

Internal Recording

Recording Media	1 x SDHC 1 x USB 3.0 Type-A
Recording Modes	1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps (MP4 via H.264/AVC) 1280 x 720p at 50/59.94/60 fps (MP4 via H.264/AVC) 720 x 576p at 50 fps (MP4 via H.264/AVC) 720 x 480p at 59.94/60 fps (MP4 via H.264/AVC)

Power

Power Connector

1 x RJ45 Input
1 x Barrel (12 VDC at 2 A) Input

General

Dimensions	8.43 x 5.36 x 1.75″ / 214 x 136.1 x 44.5 mm (Includes Protusions)
Weight	1.76 lb / 0.8 kg

Packaging Info

Package Weight	2.81 lb
Box Dimensions (LxWxH)	10.5 x 8.3 x 4.3″

Additional information

Weight	1 lbs
Dimensions	15 × 10 × 5 in
